Visual Fault Locator, FL-30(30mW)
FL-30(30mW)
Description:
Visual Fault Locator FL-30, other called pen type optical fiber tester is designed for fiber tracing, fiber routing and continuity checking, widely used in FTTH telecommunications engineering and maintenance, cabling System and other fiber-optic project.
- Model: FL-30
- Power range: 30mW
- Test distance: About 20km
- Working hours: 4H
- Output wavelength: 650nm
- Product detail
- Specification
- Video
- Our Advantages
- Inquiry
Key Features
- Optional 1.25mm interface (LC)
- Standard 2.5mm universal interface (FC, SC, ST)
- Strong light source, strong penetrating power, stable property
- Made of high quality aluminum material
- Simple operation, always on and flashing, dual mode one-key switch
- Find fiber micro-bending, breakage and fiber damage
- Crash and dust proof design for laser head
- Pocket size design and with carrying case
- competitive price
SPECIFICATION
Visual Fault Locator FL-30, other called pen type optical fiber tester is designed for fiber tracing, fiber routing and continuity checking, widely used in FTTH telecommunications engineering and maintenance, cabling System and other fiber-optic project.
The optic fiber light source can detect the fiber condition at a distance of up to 20km. The original imported laser chip allows the product to have a strong light source with strong penetrating power, and it is easy to detect line breaks. The 2.5mm interface is suitable for various optical fiber interfaces, and the replaceable ceramic core extends the service life of the product.
APPLICATION
The optical visual fault locator (VFL) is specially developed for field personnel who need an efficient and economical tool for fiber tracing,fiber routing and continuity checking in an optical network during and after installation in FTTH line constructions.
Jera is a direct factory who mainly produces fiber optic cable and relevant accessories for aerial FTTH deployments. For other cable termination tools such as Fiber cable jacket stripper, Kevlar cutting tool, fiber optic cleaning product etc you could find it in our product groups.
Welcome to send inquiry for this fiber visual fault finder price.
Manufacturing
Watch Our Factory Video
Technical specification
|
Model |
FL-30 |
|
Power range |
30mW |
|
Test distance |
About 20km |
|
Working hours |
4H |
|
Output wavelength |
650nm |
|
Laser type |
FP-LD |
|
2Hz |
Yes |
|
Linker type |
2.5mm universal interface |
|
Working temperature |
-10℃~60℃ |
|
Storage temperature |
-20℃~70℃ |
|
Power supply |
AA battery*2 |
|
Weight |
40g |
