Ratchet Cable Tensioning Puller
Puller
Description:
Ratchet tensioning puller, a hand puller ( also known as ratchet puller, power puller, or come along) is a lever operated manual device used to lift, lower, or pull a load and to apply or release tension. It utilizes a ratchet and pawl mechanical configuration to incrementally raise or lower a load or to apply or release tension. Usually applied in FTTH network construction to pull difference conductors.
- Product code: LH-20
- Pulling force, Ton Without block: 1.5
- Cable length,m: Without block: 3.0
- Pulling force, Ton With block: 3.0
- Cable length,m With block: 1.6
- Product detail
- Specification
- Video
- Our Advantages
- Inquiry
Key Features
- Flexible rotation of hooks
- Three hooks for adjusting of extra block loop
- Ratchet locking system
- Equipped with locking pin
- Reverse system is available
- Galvanized steel material
- High mechanical strength
- Competitive price
SPECIFICATION
Ratchet tensioning puller, a hand puller ( also known as ratchet puller, power puller, or come along) is a lever operated manual device used to lift, lower, or pull a load and to apply or release tension. It utilizes a ratchet and pawl mechanical configuration to incrementally raise or lower a load or to apply or release tension. Usually applied in FTTH network construction to pull difference conductors.
Ratchet tensioning puller is used for pulling conductors of a low voltage power to lifting loads by manual force, reverse can be use. It is made of galvanized steel and usually used with Come along wire grip you could place it as well.
When using, first loosen the wire rope or galvanized iron wire on the wire tightener, fix it on the cross arm, clamp the wire with the clamp, and then pull the special wrench. Due to the anti-reverse action of the pawl, the wire rope or the galvanized iron wire is gradually wound around the ratchet roller to tighten the wire. Secure the tightened wires to the insulator. Then loosen the pawl to loosen the wire rope or galvanized iron wire, then release the wire clamp, and finally wind the wire rope or galvanized iron wire around the roller of the ratchet.
Jera line is operating according to ISO 9001:2015, this allow us to sell to over 40 countries and regions such as CIS, Europe, South America, Middle East, Africa, and Asia.
Jera offers all the cable joints and accessories, which needed in construction of overheard transmission network: pole brackets, pole banding, stainless steel band and buckles,hooks, tumbuckles, shackles, cable slack storage and etc. All the assemblies passed the tensile tests, operation experience with temperature cycling test. Other fiber optic cable products and tools are available ether separately or together as assembly, feel free to inquire about this product.
Manufacturing
Watch Our Factory Video
Technical specification
|
Product code |
Pulling force, Ton |
Cable length,m |
||
|
Without block |
With block |
Without block |
With block |
|
|
LH-20 |
1.5 |
3.0 |
3.0 |
1.6 |
Product Video
FACTORY VIDEO
Factory picture
PRODUCTION FACILITY
TESTING FACILITY
Cable OTDR
test
Tensile strength
test
Temp & Humi cycling
test
UV & temperature
test
Corrozion aging
test
Fire resistance
test
