Model No. :

8.5-9.4 mm

Description:

Preformed guy grip other called dead end guy grip is developed to grip and tension adss cable during construction of internet network lines on wooden or concrete poles, as analogy of classical wedge type tension clamps.

    • Cable type: Round
    • Cable size: 8.5-9.4 mm
    • Span: <50 m
    • MBL: 4-7 KN
    CONTACT NOW download data sheet
  • Product detail
  • Specification
  • Video
  • Our Advantages
  • Inquiry

Key features

  • Easy operation, no need other tools
  • Made of hot dip galvanized steel, weather resistant
  • With sand and glue to improve friction between cables
  • Customized products is available upon requests
  • High tensile strength
  • Competitive price
Preformed Guy Grip for ADSS 8.5-9.4 mm Preformed Guy Grip for ADSS 8.5-9.4 mm

SPECIFICATION

Preformed guy grip other called dead end guy grip is developed to grip and tension adss cable during construction of internet network lines on wooden or concrete poles, as analogy of classical wedge type tension clamps.

ADSS preformed guy grip is made of high quality ASTM_A475 steel wire and processed with galvanized finish, which provide high mechanical strength and excellent environment stability. The interior side of grips are covered with sand and glue which will greatly increase the friction between conductor.

The installation of this guy grip dead end is very convenient and don’t need other tools. It is usually used on wooden or concrete poles with cable distribution construction. And we are capable to develop new product depend on the configuration from you, please just inform us the conductor size and mechanical load request, we will offer the most cost-effective and suitable product in a short time.

read more

APPLICATION

Jera line is a direct dead end guy grips manufacturer, We have introduced plenty of engineering know-how, to provide you with the ultimate in confidence when choosing our solution. Jera line is operating according to ISO9001:2015, we have our own inner laboratory to do daily inspection and test to control product quality.

We insist on reinvesting in production and R&D no less than 70% of EBITDA, that allows us to satisfy customers from more than 40 countries – worldwide.

Welcome to contact us for more information about this adss cable guy grips price.

read more

Manufacturing

    JS manufacture

Watch Our Factory Video

Technical specification

Product code

ADSS cable size,mm

Wires’ configuration

Length,mm

MBL,kn

Color

JS-4(7)-8.5/9.4

8.5-9.4

2.0*4

450

4-7

Red

Product Video

FACTORY VIDEO

Factory picture

TESTING FACILITY

TESTING FACILITY

Cable OTDR
test

Tensile strength
test

Temp & Humi cycling
test

UV & temperature
test

Corrozion aging
test

Fire resistance
test

FAQ

  • 1. What area are you in?

    We are the factory, located in China busy in production of aerial FTTH solution consist of:

    • fiber cable,
    • pre-terminated patch cords,
    • cable clamps and brackets,
    • outdoor and indoor termination boxes, access terminals

    We produce a solution for optical distribution network ODN.



  • 2. Are you the direct manufacturer?

    Yes, we are direct factory with years of experience.

  • 3. Where is your factory located?

    Jera Line’s factory located in China, Yuyao Ningbo, welcome to visit our factory.

  • 4. Why I should choose Jera Line?

    - We offer very competitive price.
    - We produce a solution, with suitable product recommendations.
    - We have the stable quality control system.
    - After sales product guarantee and support.
    - Our products were adjusted to work with each other to operate in a system.
    - You will be granted by additional advantages (cost efficiency, application convenience, new product usage).
    - We are committed to long term refashions based on trust.

  • 5. Why you can offer competitive prices?

    Because we the direct factory has competitive prices, find more info here: https://www.jera-fiber.com/competitive-price/

  • 6. Why can you offer stable quality?

    Because we have quality system, find more details  https://www.jera-fiber.com/about-us/guarantee-responsibility-and-laboratory/

  • 7. Do you offer a guarantee on your products?

    Yes, we provide product guarantee. Our vision is to build a long-term relationship with you. But not one-shot order.

  • 8. How can I save logistics cost working with you?

    You can decrease up to 5% of your logistics cost working with us.
    Save Logistic Cost – Yuyao Jera Line Fitting Co., Ltd. (jera-fiber.com)

  • 9. What are the main products that you produce?

    We produce a solution, for aerial fiber optic cable FTTH/FTTX deployment (cable + clamps + boxes), constantly developing new products.

  • 10. What's your trade term and payment terms?

    We accept FOB, CIF trade terms, and for payments we accept T/T, L/C at sight.

  • 11. Can you produce OEM orders?

    Yes, we can. Also we can customize packaging design, brand naming, etc. upon requirements.

  • 12. Can you offer me product’s Customization and R & D?

    Yes, we have RnD department, Molding department, and we consider customization, and introducing the changes to current products. All depends on your project requirement. Also can develop new product per your request.

  • 13. What's your MOQ of new customers?

    Absence of MOQ criteria for first order.

  • 14. Can you provide free samples?

    Yes, we provide samples, which will same to the order.

  • 15. Will the quality of ordered products be the same to the sample what I have confirmed?

    Sure, the quality of order products is always the same to quality of samples that you’ve confirmed.

  • 16. Where can I see yours’s products application?

    Visit our youtube channel https:/www.youtube.com watch?V=DRPDnHbVJEM8t

  • 17. How to get in touch with you?

  • 18. Where can I download your latest catalog

  • 19. Do you have global experience?

    Yes, we have. Jera line is operating according to ISO9001:2015 and we have partners and customers in many countries and regions. Every year, we go abroad to participate in exhibitions and meet like-minded friends.
