Strand wire preformed grip, JS-38SQ

Strand wire preformed grip, JS-38SQ
Strand wire preformed grip, JS-38SQ
Strand wire preformed grip, JS-38SQ
Strand wire preformed grip, JS-38SQ
Model No. :

JS-38SQ

Description:

Guy grip dead end JS-38SQ also called 지선그립 was designed to grip strand wire during installation on single wood pole associated with distribution construction, or concrete tower, as analog of classical wedge dead end strand clamps.

    • Cable type: Strand wire
    • Cable size: 7.8 mm
    • Span: not specified
    • MBL: 42 KN
    CONTACT NOW download data sheet
  • Product detail
  • Specification
  • Video
  • Our Advantages
  • Inquiry

Key Features

  • Easy installation, no requests other tools
  • Made of high quality ASTM A475 hot dip galvanized steel, weather resistant
  • With sand and glue to improve friction between strand wire
  • Customized products are available
  • With high tensile strength load up to 42KN
  • Superior environmental stability, durable
  • Competitive price
Strand wire preformed grip, JS-38SQ Strand wire preformed grip, JS-38SQ

SPECIFICATION

Guy grip dead end JS-38SQ also called 지선그립 was designed to grip strand wire during installation on single wood pole associated with distribution construction, or concrete tower, as analog of classical wedge dead end strand clamps.

Preformed dead-end grips, 38T is made of galvanized steel, ASTM A475 standard of wire, which is weather proof. We use high quality material to ensure good performance during application. The inner part of guy grips proceed with sand and glue to improve friction between strand wire.

This dead end guy grip is consist of 5* 2.8 diameter steel wire, and the tension broken load is up to 42KN. The operation of this dead end guy grip is very convenient, no request other tools. It can be mounted directly on strand wire by hands which greatly reduce the time and installation cost.

read more

APPLICATION

Customized products is also available, just inform us the diameter of strand wire and required tensile load, we will develop the most cost-effective product in a short time.

Jear line is a direct dead end guy grip manufacturer, all our produced guy grips have been inspected in order to satisfy the requirements of our clients.

Welcome to contact us for more information about this dead end grip price.

read more

Manufacturing

    JS manufacture

Watch Our Factory Video

Technical specification

Type

Strand, mm2

Wire configuration

Length, mm

MBL, KN

Color code

Weight, kg

38T,JS-42-(2.8*5)-7.8

38

2.8 * 5

660(+-50)

42

yellow

0.36

Product Video

FACTORY VIDEO

Factory picture

TESTING FACILITY

TESTING FACILITY

Cable OTDR
test

Tensile strength
test

Temp & Humi cycling
test

UV & temperature
test

Corrozion aging
test

Fire resistance
test

FAQ

  • 1. What area are you in?

    We are the factory, located in China busy in production of aerial FTTH solution consist of:

    • fiber cable,
    • pre-terminated patch cords,
    • cable clamps and brackets,
    • outdoor and indoor termination boxes, access terminals

    We produce a solution for optical distribution network ODN.



  • 2. Are you the direct manufacturer?

    Yes, we are direct factory with years of experience.

  • 3. Where is your factory located?

    Jera Line’s factory located in China, Yuyao Ningbo, welcome to visit our factory.

  • 4. Why I should choose Jera Line?

    - We offer very competitive price.
    - We produce a solution, with suitable product recommendations.
    - We have the stable quality control system.
    - After sales product guarantee and support.
    - Our products were adjusted to work with each other to operate in a system.
    - You will be granted by additional advantages (cost efficiency, application convenience, new product usage).
    - We are committed to long term refashions based on trust.

  • 5. Why you can offer competitive prices?

    Because we the direct factory has competitive prices, find more info here: https://www.jera-fiber.com/competitive-price/

  • 6. Why can you offer stable quality?

    Because we have quality system, find more details  https://www.jera-fiber.com/about-us/guarantee-responsibility-and-laboratory/

  • 7. Do you offer a guarantee on your products?

    Yes, we provide product guarantee. Our vision is to build a long-term relationship with you. But not one-shot order.

  • 8. How can I save logistics cost working with you?

    You can decrease up to 5% of your logistics cost working with us.
    Save Logistic Cost – Yuyao Jera Line Fitting Co., Ltd. (jera-fiber.com)

  • 9. What are the main products that you produce?

    We produce a solution, for aerial fiber optic cable FTTH/FTTX deployment (cable + clamps + boxes), constantly developing new products.

  • 10. What's your trade term and payment terms?

    We accept FOB, CIF trade terms, and for payments we accept T/T, L/C at sight.

  • 11. Can you produce OEM orders?

    Yes, we can. Also we can customize packaging design, brand naming, etc. upon requirements.

  • 12. Can you offer me product’s Customization and R & D?

    Yes, we have RnD department, Molding department, and we consider customization, and introducing the changes to current products. All depends on your project requirement. Also can develop new product per your request.

  • 13. What's your MOQ of new customers?

    Absence of MOQ criteria for first order.

  • 14. Can you provide free samples?

    Yes, we provide samples, which will same to the order.

  • 15. Will the quality of ordered products be the same to the sample what I have confirmed?

    Sure, the quality of order products is always the same to quality of samples that you’ve confirmed.

  • 16. Where can I see yours’s products application?

    Visit our youtube channel https:/www.youtube.com watch?V=DRPDnHbVJEM8t

  • 17. How to get in touch with you?

  • 18. Where can I download your latest catalog

  • 19. Do you have global experience?

    Yes, we have. Jera line is operating according to ISO9001:2015 and we have partners and customers in many countries and regions. Every year, we go abroad to participate in exhibitions and meet like-minded friends.
