FTTH cable drop wire clamp Fish-45

Fish-45

Ftth cable drop wire clamp Fish-45 is a fiber drop cable tension clamp used to tension fiber optical cable on the dead-ending or down lead routes in outdoor FTTx line deployment.

Features

Cable type: Round
Cable size:4-5 mm
Span:＜70 m
MBL: Depend on cable

DESCRIPTION Specification Test

REVIEW

Key Features

Cost-effective
Self-adjustable rotation
Simple and fast installation, requiring no tools
UV resistant plastic and stainless steel material, durable
Won’t hurt cable outer jacket during application
Perfect environment stability
Fair price

FTTH cable drop wire clamp Fish-45

SPECIFICATION

The clamp applied in:

Cable diameter: 4-5 mm

MBL, kN: depend on cable

The cable clamp is used to connect and fix the optical cable wires, the groove body, the wire frame and the rod, and constitutes a cable clip as a whole.

The interior is designed with grooves or patterns to increase the friction between the clamp and the wire to prevent loosening or falling off.

The wire rope of the wire clamp is made of stainless steel 304. The length is determined by the customer’s needs.

The shell is made of plastic with good insulation and strong UV resistance, which can not only protect the optical cable from the impact of the external environment, but also prevent the short circuit or electrical leakage of the wire and optical cable in contact with other components.

APPLICATION

The FISH-45 drop wire clamp is used for anchoring fiber optic drop cables in FTTH and FTTX aerial network systems.

It is typically installed on poles, walls, and building entry points to provide secure cable fixation between distribution networks and subscriber premises.

This clamp is widely applied in last-mile fiber optic deployment, broadband access networks, and telecommunication infrastructure projects. It ensures stable cable tension while minimizing mechanical stress on the fiber optic sheath. The FISH-45 is suitable for residential, commercial, and industrial fiber installation scenarios requiring reliable and long-term outdoor performance.
