Model No. :

1:9 Fiber Optic FTTH Unbalanced 85-15

Description:

1:9 Fiber Optic FTTH Unbalanced 85-15 also called Unbalanced Coupler Fiber Optic PLC Splitter, is a type of optical fiber distribution system commonly used in Fiber-to-the-Home (FTTH) networks. It refers to the configuration where the optical power is divided unequally between two paths.

    • Type: 1×9

    • Adapter type: SC
    • Polish type: APC
    • Area: Indoor
    CONTACT NOW download data sheet
  • Product detail
  • Specification
  • Video
  • Our Advantages
  • Inquiry

Key Features

  • low insertion loss, ensuring minimal signal degradation during transmission
  • wide wavelength range, allowing compatibility with various optical signals
  • exhibits high reliability
  • the system offers scalability, allowing for future expansion and modification
  • Factory direct sale
1:9 Fiber Optic FTTH Unbalanced 85-15 1:9 Fiber Optic FTTH Unbalanced 85-15

SPECIFICATION

1:9 Fiber Optic FTTH Unbalanced 85-15 also called Unbalanced Coupler Fiber Optic PLC Splitter, is a type of optical fiber distribution system commonly used in Fiber-to-the-Home (FTTH) networks. It refers to the configuration where the optical power is divided unequally between two paths.

FTTH Fiber 1×9 PLC Coupler With SC/APC refers to the configuration where the optical power is divided unequally between two paths, with 85% of the power directed to one path and 15% directed to the other path.

read more

APPLICATION

This particular system is designed to provide optical connectivity for up to nine end-users from a centralized optical splitter. Fiber Optical 1×9 Splitter is responsible for dividing the incoming signal from the service provider into multiple downstream signals, enabling simultaneous transmission to multiple users.

Jera line is operating according to 9001:2015 and has our own laboratory to assume the quality of products. Each batch of products has passed the experiment and reached European standards. There is also a sales team with outstanding ability to serve 24 hours. If you want to order patch cord、fiber optic terminal box、PLC splitter and so on, act fast!

Feel free to contact our sales team for more details for this 1×9 PLC Splitter With Connector SC/APC.

read more

Manufacturing

    fiber optic splitter manufacture

Watch Our Factory Video

Technical specification

Package Style

Mini Module

Configuration Type

1×9

Fiber Grade

G.657A1

Fiber Mode

Singlemode

Connector Type

SC/APC

Split Ratio(CH1)

85%

Input/Output Fiber Diameter

900μm

Input/Output Fiber Length

1.5m

Insertion Loss

≤ 16.5dB

Return Loss

≥ 55dB

Loss Uniformity

≤ 0.5dB

Directivity

≥ 55dB

Polarization Dependent Loss

≤ 0.2dB

Temperature Dependent Loss

≤ 0.5dB

Wavelength Dependent Loss

≤ 0.3dB

Operating Bandwidth

1260~1650nm

Steel Tube Dimensions (HxWxD)

0.16″x0.47″x2.36″ (4x12x60mm)

Temperature

Operating -40 to 85°C (-40 to 185°F)
Storage -40 to 85°C (-40 to 185°F)
