Preformed tension dead-end grip- Strand Wire Guy Grip 38T
Jera Line is a specialized manufacturer of cable infrastructure products, all exclusively engineered for outdoor applications.
The video you are watching demonstrates the assembly process of our Preformed Tension Dead-End Grip — specifically the Strand Wire Guy Grip 38T model.
This preformed tension dead-end grip is typically used in the installation of exposed conductors, electric transmission & distribution lines, and overhead insulated conductors. It can replace the tension clamps (including the widely used bolt-type ones) currently employed in power lines.
Featuring a simple structure, it consists of two "legs" of preformed armor rods twisted around a blank pipe, with a twisted ring at its rear end. When the blank pipe wraps around the conductor, it generates strong holding force.
This strand wire guy grip is independently developed by Jera Line.
For additional details, please do not hesitate to contact us via
Email: info@jera-fiber.com
Youtube:https://www.youtube.com/@jeraline
Product’s features:
-
Crafted from materials compatible with the strand it is applied to, ensuring optimal matching and performance.
-
Lay direction must align with that of the outer layer of the paired strand to avoid structural mismatch or tension loss.
-
The loop of the Guy-Grip Dead End is engineered to work with thimbles and stay rod eyes.
Technical specification
|
Product code
|
38T
|
|
Strand rope mm²
|
38
|
|
Grip’s configuration
|
2.8*5
|
|
Length,mm
|
660
|
|
MBL,KN
|
42
|
|
Color
|
Yellow
|
|
Weight,KG
|
0.36
|
Application
The Preformed Strand Wire Guy Grip 38T is mainly used in power system infrastructure and outdoor cable support scenarios, with three core application directions:
-
Power Transmission & Distribution Lines
-
Overhead Cable Installation
-
Guy Wire & Support Structure Fixing
Test
Ultimate tensile strength test
Ultimate tensile strength test other called maximal mechanical tensile test which used to measure the ability to withhold mechanical loads of products.
This is a mechanical test where a pulling force is applied to a material from both sides until the sample changes its shape or breaks. It's is a common and important test that provides a variety of information about the material being tested, including the elongation, yield point, tensile strength, and ultimate strength of the material.
Jera proceed this test on below products
Endurance test on failure tension testing equipment under mechanical and thermal stresses with oscillation stress has different values according to standard IEC 61284 for overhead fiber optic cable, and accessories.
We use following standards test on new products before launching, also for the daily production, in order to make sure ours customer could receive products which meet quality requirements.
Our internal laboratory is capable to proceed such a series of standard related type tests.
Welcome to contact us for further information.
