Fiber Optic Duplex Patch Cord MM OM2 LC/UPC -LC/UPC

Fiber Optic Duplex Patch Cord MM OM2 LC/UPC -LC/UPC is a type of fiber optic patch cord, which has two LC/UPC connectors. This fiber optic patch cord is duplex (2 fibers), and has connectors at both ends, which can be quickly connected to other devices. Due to its low insertion loss, it is widely used in fiber optic cable distribution.

Features

LSZH Jacket
Duplex design, send and receive data
Low insertion loss and back reflection loss
Flexible cabling
Fiber core size 62.5/125 μm
Good echangeability
Fair price

DESCRIPTION Specification Test

REVIEW

Applied in optical transmitter, receiver, PON boxes and other telecommunication equipment during FTTX solutions.

Jera Line is a Chinese factory specializing in the production of fiber optic cables, boxes and **fiber optic patch cords** . This product belongs to the OM series and adapts to the LC/UPC equipments. If you also need other SC, LC or other connectors, Jera’s OM series products can meet your basic needs for such products. For more information, please view other products on the website or contact us to ask our sales team.

Technical specification

Connector Type	LC/UPC to LC/UPC
Fiber Count	Duplex
Wavelength	850/1300nm
Fiber core size	62.5/125 μm
Insertion Loss	≤0.2dB
Min. Bend Radius (Fiber Core)	7.5mm
Min. Bend Radius( Fiber Cable)	20/10D (Dynamic/Static)
Cable Jacket	LSZH
Polarity	A (Tx) to B (Rx)
Return Loss	≥30dB
Attenuation at 850nm	3.0 dB/km
Attenuation at 1300nm	1.0 dB/km
Cable Diameter	2.0mm
Operating Temperature	-20~70°C
