SUS 304 ODWAC clamp

SUS 304 ODWAC clamp

ODWAC clamp other called aerial drop clamp is designed to tension ftth flat cable or telephone wire on dead-ending or intermediate routes during aerial FTTH line constructions.

Features

Cable type: Flat
Cable size:<6×<13mm
Span:30-50 m
MBL: 1.2KN

DESCRIPTION Specification Test

REVIEW

Key Features

No need other tools, hand installation
SUS 304 grade stainless steel, durable
Shim with 2 rows total 26 holes to increase the friction between drop cable
Applied with drive hook,pole bracket or other fittings
Superior environmental stability
Fair price

The clamp applied in:

Cable diameter: <6×<13mm

MBL, kN: 1.2

The cable clamp is used to connect and fix the optical cable wires, the groove body, the wire frame and the rod, and constitutes a cable clip as a whole.

The interior is designed with grooves or patterns to increase the friction between the clamp and the wire to prevent loosening or falling off.

The length is determined by the customer’s needs.

The shell is made of 304 stainless with strong UV resistance, which can not only protect the optical cable from the impact of the external environment, but also prevent the short circuit or electrical leakage of the wire and optical cable in contact with other components.

read more

Applied outdoor, for installation on the telecommunication supports, between the buildings and industrial constructions to fix and protect optical cables.

read more

Manufacturing

Watch Our Factory Video

Technical specification

Product code	Flat cable size (h×w) mm	Material	MBL,KN	Length,mm	Weight,kg
ODWAC-22	<6×<13	304 Stainless steel	1.2	220	0.04
