ADSS cable anchor clamps are critical components for ADSS (All-Dielectric Self-Supporting) cables, designed to secure the cables firmly to overhead supports (such as utility poles or towers) and ensure the stability and reliability of fiber optic networks. By preventing the ADSS cable from shifting, sagging, or sustaining damage due to environmental stress or mechanical load, these anchor cable clamps effectively minimize the risk of communication system failures and costly downtime.
Crafted with robust, corrosion-resistant materials (e.g., high-grade aluminum, stainless steel), ADSS anchor clamps deliver exceptional durability and load-bearing capacity. This rugged construction enables them to withstand harsh outdoor conditions—including extreme temperatures, UV radiation, and wind loads—while maintaining long-term performance, thereby extending the lifespan of the entire overhead fiber optic infrastructure.
Construction
Anchor clips for ADSS cables are special metal elements that fix the cable to the supports. They often have special ribs and protrusions that guarantee a secure grip on the surface of the support. Some design elements:
-
Open thermoplastic housing, resistant to mechanical damage and exposure to weather and climatic conditions.
-
An inner wedge made of insulating material, which provides compression of the cable without damaging its insulating coating.
-
Flexible stainless-steel hinge, equipped with a seat made of insulating material to protect against wear and two tips pressed at the ends to lock on the clamp body.
The principle of operation
The cable anchor clamp tightly wraps around the cable, distributing the load evenly. This is important, especially in strong winds or during temperature fluctuations, when the cable may experience significant mechanical stress.
There is also a plastic loop on the clamp cable that insulates the bearing element when it is closed to the mass of the support.
Selection rules
When choosing anchor clips for ADSS cables, the cable characteristics and operating conditions must be taken into account. Parameters such as the diameter of the cable, the expected load on the line, as well as the type and material of the support are important.
It is not recommended to use anchor clamps if the power element is made of steel wire. If the load is prolonged, the teeth of the wedges will begin to slip along the wire with a smooth surface, which can cause damage to the cable.
Mounting
To install the anchor clips correctly, it is important to follow the manufacturer's instructions. Improper fastening can damage the cable or loosen its fastener. It is recommended to entrust the installation to qualified specialists who will be able to correctly select and install the clamps.
Jera Line is a leader Chinese manufacturer specializing in the manufacture of first-class anchor clamps.
With advanced production facilities and a team of highly qualified engineers, the factory adheres to strict quality control rules, ensuring that each anchor clamp meets international standards. Based on advanced technology and high-quality materials, Jera Line products are renowned for their durability, excellent performance, and superior corrosion resistance. Whether for ADSS cable routing or other demanding applications, these anchor clamps provide reliable mechanical support, precisely engineered to withstand harsh environmental conditions and heavy loads. Jera Line's commitment to innovation and quality makes it a reliable partner for customers who require high-performance anchor clamp solutions. For more information or to get started on your next project, please contact us. Jera Line is a leading manufacturer in China. Our team is here to help you choose the best ADSS cable anchor clamps for your fiber optic network!
