Pre-terminated Fiber Optic Cable
/
Outdoor Pre Terminated Drop Cable

FTTH fiber drop cable patchcord SC/APC 100M

FTTH fiber drop cable patchcord SC/APC
FTTH fiber drop cable patchcord also called outdoor optical drop cable patch cord is a fiber drop cable terminated with connectors at each end, it helps end user to speed up cable line deployment and save operation cost.
FTTH fiber drop cable patchcord SC/APC 100M
Features
    • Application: Outdoor/Indoor
    • Fiber quantity: 1 fiber
    • Cable dimensions: 2.0*5.0 mm
    • Length：100 m
Contact Us
DESCRIPTION Specification Test
REVIEW

Key Features

  • Each end terminated with SC/APC connector
  • Reinforced with steel wire and rods
  • UV resistant LSZH cable jacket
  • Low polarization dependent loss
  • High reliability
  • Competitive price
FTTH fiber drop cable patchcord SC/APC 100M FTTH fiber drop cable patchcord SC/APC 100M

SPECIFICATION

The cable patch cords consists of:

  • The cable dimensions:

- Width : 5.0 ± 0.2mm

- Height: 2.0±0.2mm

  • Fiber quantity is 1 fiber.
  • LSZH jacket sheath, UV protected.

Optical fiber of Single modeG652D, G657A1, G657A2 grades of fiber standards.

LSZH is a sheath material is halogen-free (no chlorine and fluorine). This material does not produce dense smoke and does not produce toxic gases when burned. The fire protection grade maybe chosen by the customer according to CPR, mentioned in EN 50575. The test maybe conducted according to IEC / EN 60332-1-1.

read more

APPLICATION

Applied in tooptical transmitter, receiver, PON boxes and other telecommunication equipment during FTTX solutions.

read more

Manufacturing

patch cord manufacture

Watch Our Factory Video

Technical specification

Item

Value

Polish types

SC/APC

Fiber cores

G652D, G657A1, G657A2

Fiber counts

Simplex

Fiber modes

Single-mode 9/125

Cable color

Black

Size,mm

2.0*5.0

Tensile strength

2000N

Length,m

100

Insertion losses(IL),dB

≤0.3

Material

LSZH

Working temperature

-40~+85℃

Product Video
