FIG.8 MESSENGER SUPPORTING CABLE & CLAMP SYSTEM

FIG. 8 illustrates a messenger supporting cable & clamp system, which typically consists of a messenger cable serving as a structural support and clamps for securing additional cables or components. The system is designed to distribute loads evenly, ensuring stability and preventing sagging. Messenger cables, often made of steel or synthetic materials, withstand tensile forces, while clamps are engineered for easy installation and reliable fixation. This setup is commonly used in overhead wiring, bridge suspensions, or industrial installations to support heavy cables efficiently and safely.

1.FIG.8 MESSENGER SUPPORTING CABLE

FIG.8 shows a messenger supporting cable, which is designed to bear the weight and tension of messenger wires in overhead power or communication line systems. The cable features a robust structure, made of high-strength materials like steel or composite alloys, to ensure durability and reliability. It have a stranded design for flexibility while maintaining mechanical strength, and connectors or fittings at both ends for secure attachment to supporting structures. This component plays a crucial role in stabilizing the overhead lines, preventing sagging and ensuring safe operation.

Technical specification

2.FIG.8 MESSENGER SUPPORTING CLAMPS

The figure 8 cable anchoring clamp is a specialized device for securely fastening cables. Shaped like the numeral "8", it features two loops connected at the center, allowing cables to pass through each loop. Made from durable materials like steel or aluminum, it ensures reliable anchoring by distributing tension evenly. This clamp prevents cable slippage and provides strain relief. Its design allows for easy installation and adjustment, making it essential for maintaining cable stability in various applications.

PA-0 / PS TYPE CLAMPS

Technical specification

Product code	PA-05	PA-06	PA-07	PA-07X	PA-010X
Messenger's Material	Steel	Steel	Steel	Steel	Steel
Diameter of Wire over the Insulation*	ø3-5	ø3-6	ø3-7	ø4-7	ø5-10
MBL,kn	2.0	3.0	5.0	3.0/7.0	16.0
Materials	Stainless steel UV resistant plastic Aluminum,zink

Product code	PS-SS	PS-CS	PS-D1	PA-09
Diameter of Wire over the Insulation*	ø4-5/5-9	ø4-5/5-9	ø4-7	ø2-9-3.6
MBL,kn	8.0	8.0	0.5	5.0
Material	Galvanized steel UV resistant plastic	Galvanized steel UV resistant plastic	Galvanized steel UV resistant plastic	Stainless steel, aluminum

KEY FEARURE

1.Wide choice for different SPAN and specific size of messenger

2.Special pattern for proper grip

3. Stainless steel wire bail

4.X-type clamp does not cut the jacket at peak load.

CONCLUSION

Jera Line offers a comprehensive FIG.8 Messenger Supporting Cable & Clamp System, engineered for dependable fiber-to-the-home (FTTH) network deployments. The FIG.8 design integrates a strong messenger for structural support, ensuring stable installation across indoor and outdoor environments. Paired with precision clamps, it simplifies secure mounting, reducing installation time and enhancing long-term reliability. Ideal for extending high-speed fiber connections, this system meets stringent industry standards, guaranteeing consistent performance for residential and small business networks. A trusted solution for efficient FTTH infrastructure buildouts.
