Fiber optic PLC splitter 1×2 SC/APC

1×2 SC/APC

Fiber optic PLC( Planar lightwave circuit) splitter other called blockless fiber PLC splitter, is a type of optical power management device that is fabricated using silica optical waveguide technology to distribute optical signals from Central Office (CO) to multiple premise locations.

Features

Type: 1×2
Adapter type: SC
Polish type: APC
Area: Indoor

DESCRIPTION Specification Test

REVIEW

Key Features

Low insertion loss(IL)
Low polarization dependent loss (PDL)
Compact structure allow applied with various termination boxes
Easy and low cost FTTH installation
Excellent environmental stability
Competitive price

Fiber optic PLC( Planar lightwave circuit) splitter other called blockless fiber PLC splitter, is a type of optical power management device that is fabricated using silica optical waveguide technology to distribute optical signals from Central Office (CO) to multiple premise locations.

Fiber optic splitter is a kind of ODN product suitable for PON networks that can be installed in the pigtail cassette, test instrument and WDM system, which minimizes the space occupation.

The blockless PLC splitter can allow a single GPON network interface to be shared among many subscribers and allow service providers to enable bandwidth-intensive applications. The blockless splitter features small size, which is an intermediate choice between volume miniaturization and reliable fiber protection. It is suitable for installation in your system design and manufacturing The PLC splitter we offer are: 1×2, 1×4, 1×8, 1×16, 1×32,1×64.

read more

The package of this PLC splitter is simple carton box. The pallet packing method is available as well, check more details with our sales.

Jera line is operating according to ISO 9001:2015, this allow us to sell to over 40 countries and regions such as CIS, Europe, South America, Middle East, Africa, and Asia.

We supply fiber optical cable accessories for FTTH constructions and provide the whole kit of accessories to our customers, such as **fiber optic cable** , cable clamps, cable bracket, fiber optic termination boxes, adapters, patch cord and so on.

Welcome to contact us about Fiber optic PLC splitter price.

read more

Manufacturing

Watch Our Factory Video

Technical specification

Type		1×2
Operating wavelength (nm)		1260-1650
Optical fiber thickness,mm mmmm		0.9
Optical fiber type		G657A1,G657A2
Adapter type		SC
Polish type		APC
Insertion loss(dB)	Typical	10.5
Insertion loss(dB)	Maximum	10.7
Uniformity(dB)	Typical	0.6
Uniformity(dB)	Maximum	0.8
Polarization Dependent Loss(dB)	Typical	0.15
Polarization Dependent Loss(dB)	Maximum	0.25
Wavelength dependent Loss(dB)	Typical	0.15
Wavelength dependent Loss(dB)	Maximum	0.3
Return loss(dB)	Maximum	55/50
Directivity(dB)	Maximum	55
Operating temperature ℃		-20 to 85
Storage temperature ℃		-40 to 85
Optical fiber length (m)		0.5, 1.0, 1.5
