Fiber optic distribution box, FODB-8+C1-1*8

FODB-8+C1-1*8

Fiber optic distribution box other calls fiber optic splitter closure, designed to terminate feeding optical cable and connect last mile cables as fiber optical cords, patch cords, pigtail cords according to capacity of distribution box, it can be applied outdoor, poles and walls.

Features

Applied in main line or last mile cable’s transit & termination.
Gel sealed ideal protection, IP 68.
High quality UV resistant thermoplastic, wet and dust proof for long time usage.
2 cable inputs and 8 outputs ports.
Quick and easy access for further drop cable connections.
Stainless steel straps or screw bolt installation.
Screw lock design and superior environmental protection.
Competitive price.

DESCRIPTION Specification Test

REVIEW

Applied to outdoor walls or pillars, for connecting optical fiber lines and transmitting signals.

Technical specification

Product code	Fiber’s capacity	Inputs & cable diameter,mm	Outputs & cable diameter,mm	Dimensions, mm	Splitters
FODB-8+C1-1*8	8	2×Φ5-12mm	8×23 or 8Φ3mm	23515850	1× 1*8 PLC SC/APC or SC/UPC

Test

UV and temperature aging test other called climate aging test to examine the quality of materials or products if they meet expected functionality and lifetime. This test simulates different weather conditions, such as high humidity, high UV-radiation and high temperature.

We proceed test on almost all the overhead cable products

-Anchor clamps

-Fiber optic cable

-Fiber optic splice closures

-Fiber optic distribution boxes

-FTTH drop cable clamp

Test chamber was preformed automatically, which can avoid human mistakes to make sure the the authenticity and precision of the experiment. Climatic aging test procedure involves put products into chamber with presetting humidity, UV radiation, temperature.

Test preformed by dozen of cycles of rising and falling mentioned criteria. Each cycle includes some hours of aggressive climatic conditions. All controlled by radiometer, thermometer etc. The radiation, temperature, humidity ratio and time have different values base on standard IEC 61284 for overhead fiber optic cable, and accessories.

We use following standards test on new products before launching, also for the daily quality control, in order to make sure ours customer could receive products which meet quality requirements.

Our internal laboratory is capable to proceed such a series of standard related type tests.
