Fiber optic cable termination box FODB-24

Fiber optic cable terminaion box, FODB-24 fibers

FODB-24 fibers

Fiber optic cable termination box FODB-24 also called 24 core fiber distribution box, is a device used to terminate and distribute feeder optic cable to fiber optical cords, patch cords, pigtail cords on the routes of last mile to users during FTTH telecommunication network constructions.

Features

Feeding cable: 2 of Ø15
Drop cable: 24 of Ø3, 3 of Ø10
Max splicing capacity: 24 fibers
Adapter SC type: 24

DESCRIPTION Specification Test

REVIEW

Key Features

2 cable inputs and 27outputs ports
Anti-vandal lock provide security
Intergrated seal sealed , wet and dust proof
Appropriate for PLC splitters, SC adapter installation
Made of high quality ABS and PVC, with high mechanical strength
Provide quick and easy access for drop cable connection
Easy operation, screw installation on wall and stainless steel bands on pole
Excellent environment stability
High mechanical strengths
Competitive price

The cable boxes consist of:

The box dimensions:

- Length : 350 mm

- Width：280 mm

- Height: 100 mm

Adapter SC type: 24

Material: ABS

Fiber optic box is a connection device in fiber optic communication, which usually consists of a casing, a base, a plug board, a panel, a protection piece, and a distribution frame. The device is used to provide functions such as fiber optic cable connection, amplifier access, protection and distribution of fiber optic cable ends.

ABS plastic is a terpolymer of three monomers: acrylonitrile (A), butadiene (B) and styrene (S). A makes it resistant to chemical corrosion, heat, and has a certain surface hardness, B makes it have high elasticity and toughness, and S makes it have the processing and molding characteristics of thermoplastics and improve electrical properties.

read more

Applied to outdoor walls or pillars, for connecting optical fiber lines and transmitting signals.

Applied to indoor, for Splicing indoor optical cables and protecting the pigtail.

read more

Manufacturing

Watch Our Factory Video

Technical specification

Product code	Feeders	Inputs cable diameters, mm	Output drop cables, mm	Dimensions, mm	Adapter	Material
FODB-24	2	2 of max dia 15mm	24 of max dia 3mm and 3 max dia 10mm	350280100	24 SC	ABS,PVC
